An air compressor problem could stem from one of many issues, such as an air leak, an oil leak or a broken part. In some cases, you might have insufficient pressurization or air flow. In other cases, the compressor might fail to start up or stop running as prompted. Whatever the cause of the problem, the symptoms can be frustrating, costly and time-consuming. Thankfully, most such problems can be corrected with proper air compressor troubleshooting.
An air leak could be down to one of several factors. Fortunately, leaks can be sealed with the right kind of air compressor troubleshooting. The following symptoms are among the most common leak-related air compressor problems:
1. Compressor Is Constantly Leaking
If you shut off the air compressor on full charge, yet the gauge drops while the compressor is deactivated, you definitely have an air leak. The compressor might even automatically restart just to counter the situation. What you need to do in this situation is pinpoint the source of the leak.
- Apply soap to the connections: With the compressor unplugged, cover the connections with liquid soap, including all the couplers and the pressure switch. If bubbles form at any point, that is where the leak is located. Tighten up the coupler, if possible, where the bubbling occurs.
- Inspect the tank check valve: Air leaks are sometimes caused by tank check valves that fail to close completely. If the pressure gauge continues to drop when the tank is off, access the tank valve and inspect its condition. The valve might need to be cleaned or replaced.
If the air leaks occur only when a hose is plugged into the compressor, disconnect the hose. If the pressure gauge stops dropping, the hose is the source of your leak.
2. Air Leaks From the Oil Fill Tune
If your compressor is losing pressure through the oil fill tube, check the piston seals. In most such cases, the piston seals will be badly worn and in need of immediate replacement. This is a problem that you should remedy immediately, as worn pistons can cause metal-on-metal friction that could swiftly lead to internal corrosion.
3. Air Leaks From the Hood
Air leaks from under the hood are sometimes encountered on smaller air compressors. To diagnose the problem, remove the hood, run the compressor for a few minutes, then shut it off and unplug the compressor. Feel around the motor parts for any sort of air draft. Chances are, the leak will originate from the tank valve, in which case you will need to remove and clean or possibly replace the valve.
Electrical Motor and Power Problems
If the power cuts out on your air compressor — or the power is insufficient and unreliable — the problem is most likely down to one of the following factors:
1. Compressor Blows Fuses and Breakers
Assuming that your compressor is plugged into a working outlet and powered on, the following issues could be causing fuses to blow:
- Extension cords: If your compressor is connected to an outlet via an extension cord, the motor could be deprived of sufficient energy, causing the motor to overheat. Compressors are not like home electronics, which can suffice on extension cords and power bars. An air compressor should only be powered through a direct connection to a power source.
- An old motor: If your compressor has run on the same motor for many years, it could be time for a change-out. An older motor is liable to have worn windings, loose capacitor wires and other general wear that could easily result in blown fuses and breakers.
If the tank seems to lug at times of high pressurization, there is probably an issue with the motor capacitor.
2. Dimmed Compressor Lights at Startup
An air compressor consumes massive volumes of power at the time of startup. This is known as the inrush, which vastly exceeds the amount of power generally consumed throughout the rest of a usage cycle. To prevent fuses from breaking during this inrush, compressor motors are equipped with starter capacitors, which manage the incoming power. A dimming light is one of the tell-tale signs that the starter capacitor is worn and due for a replacement.
3. Breaker Trips at Startup
If your air compressor trips off the moment it powers on, the issue is likely caused by trapped air over the pistons. To test for this problem, shut off the tank, unplug it from the power supply and drain the tank of all air. This should relieve the pistons of undue air pressure and allow the tank to start without further issues. Trapped air over the pistons is usually caused by a faulty unloader valve, which should be inspected, cleaned and possibly replaced if the issue persists.
Won’t Start or Won’t Stop
When an air compressor fails to start up, shut down or provide any degree of air pressure while active, the problem could be down to one of several issues. Each case should be taken on its own, as follows:
1. Compressor Fails to Start
Aside from the obvious oversights such as a disconnected power cord or a deactivated power switch, a compressor will typically fail to start when it lacks sufficient air pressure. If the cut-in pressure is not proportional to the amount of air pressure stored in the tank, the compressor will often fail to start. Check the cut-in setting on the pressure switch and adjust the level accordingly.
2. Compressor Fails to Stop
The compressor should stop once the tank pressure drops to the cutoff point. If this fails to occur, the problem will generally be down to one of two issues:
- Faulty pressure release valve: If the valve fails to release pressure, the tank will be too pressurized for the motor to stop running. In cases like these, you should cut the power and refrain from further use until the valve is replaced, as further use could seriously damage the compressor.
- Faulty pressure switch: If the pressure switch fails to signal the internal controls, a new switch should solve the problem.
Pressurization components are at the heart of a compressor’s functions and when they fail, the compressor essentially fails.
3. Compressor Runs But Fails to Generate Air Pressure
If the compressor runs and runs yet air pressure is not forthcoming, the problem is likely due to one of two issues:
- Faulty pump: If the motor is running and making noise yet the compressor yields no air, you probably have a faulty air-intake pump that needs to be replaced. As long as the compressor is not too hot, you can feel for lack of pump pressure manually with a pair of protective gloves.
- Faulty gasket: If the compressor only generates small amounts of pressure, there might be an issue with the gasket between the low-pressure and high-pressure compartments of the compressor, such as air flowing from one side to the other without sufficient pressurization.
Fortunately, pumps and gaskets can easily be changed out, allowing you many more years of performance from the compressor at hand.
Oil in Air Lines
If compressor oil works its way into the air lines, the effects could be detrimental elsewhere in the compressor because the pump uses a different kind of lubricant than other parts of the system. Once inside the air lines, that oil will be dispersed to other areas, potentially causing seals to crack or swell. Oily air lines are most troubling when the oil travels to plastic parts of the air valve.
The ill-effects of oil on plastic are due to the additives in the oil, which can cause plastic surfaces to become brittle and ultimately split. A plastic lubricator bowl, for example, could split under such circumstances if the air pressure crosses a certain threshold. You can protect the bowl — or contain the plastic in the event of a rupture — by affixing it with a metal shroud.
In a reciprocating air compressor, the oil must first travel past the piston seals to make its way to the tank. When this occurs, the seals should be replaced immediately. This would also be an opportune time to replace the valve and gasket.
As soon as you notice that oil has entered the air lines, check the sump to make sure that it still has a sufficient quantity of oil. If the problem persists, the sump could be depleted of its oil supply.
Pressure and Flow Problems
Some of the most common problems with air compressors involve issues with the pressure and flow, which often manifest with the following symptoms:
1. Obstructed Intake Filter Media-Element
The main reason to replace an intake filter is when it becomes corroded or damaged. However, the filter could be the source of pressure and flow issues if the intake becomes plugged. Tell-tale signs of trouble include the following symptoms:
- The compressor tank takes longer and longer to build air.
- The motor recurrently overheats and trips the thermal cut.
If you experience these problems, remove the filter housing from the intake pump and run the compressor again. If the problems cease and the compressor runs normally, the issue is rooted in the air intake media. You can replace the media with various types of filter elements sold at supply stores and car parts shops. The best options are media that resemble the kinds used in air conditioners. Cut the media to the dimensions of the intake filter and switch out the old for the new.
2. No Air From the Hose
If an air hose is connected to your compressor yet the air is not forthcoming, the issue could be down to one of several factors:
- The tank lacks air. This would be indicated by a zero pressure reading on the tank gauge.
- The regulator pressure is set to zero. If so, adjust the regulator to a level within 20 psi of the compressor’s cutout pressure.
- The discharge coupler is fitted with the wrong hose connector, thus blocking the flow of air. This could be the case if you recently replaced one of the parts without checking OEM specifications.
The problem could also be down to the simple fact that the connector on the attached pneumatic tool is ill-suited for the coupler.
3. Air Only Comes in Short Bursts
If your tank has sufficient air quantity, yet generates very little air pressure, check the gauge readings. If the gauge is too low, you will not get sufficient air pressure from the tank. If your tank gauge is 100 psi, the gauge should be set to somewhere around 90 psi.
Parts and Repair Needed
If an air compressor seems to have stopped working due to a broken part, you first need to test the part to verify the root of the problem. A compressor will not work if the following parts are broken. Fortunately, all can be replaced:
1. Broken Intake Filter
The intake filter is a crucial part of the air compressor because it strains impure particulates from the incoming air. Since it physically sticks out from the rest of the unit, an intake filter is one of the more easily broken parts to an air compressor. Fortunately, it is also one of the easier parts to replace. As long as you find a filter with the same thread size and roughly the same portal size and diameter, it should work for your machine.
2. Broken Air Compressor Manifold
If you break the pressure switch on an air compressor, you might be surprised by the underlying complexities. Fact is, any old replacement switch will not solve the problem due to all the connecting points of the manifold. To fix the problem, you will need to find a switch that accommodates each of the four or five connecting points, which will generally include sockets for the pressure relief valve, the air tank gauge, the compressor tank and the quick coupling.
Before you buy a new pressure switch and manifold, take note of the following details on the old switch, each of which must be matched on any new switch you attach to the compressor:
- The number of ports on your pressure switch and manifold.
- The voltage of the original pressure switch.
- The cut-in and cut-out settings on the old pressure switch.
- The hookup of the unloader valve.
Be careful to properly thread the ports of the new manifold onto their corresponding parts of your air compressor.
3. Broken Compressor Fan
Many newer air compressors — particularly those on the lower-cost end of the spectrum — are equipped with fans made of plastic, which is less expensive than metal but is also more easily prone to wear and tear. Fortunately, a replacement fan made of either material will work in almost any compressor. Therefore, if you have a fan with broken plastic blades, you could turn this into an opportunity to upgrade to metal.
Before you pick a replacement fan, check the compressor manual for a listing of the part number and corresponding dimensions. If not found, measure the dimensions and the hole diameter of the original fan. Take note of the number of blades and the direction of airflow, as both details are consequential to the performance and make of the compressor.
4. Broken On/Off Switch
If the motor of your air compressor fails to power on when you flip the switch, it could be a matter of the switch itself, though you should run some tests before you draw any conclusions. Check the power cord to ensure that it is plugged into a functioning socket. If the power switch still fails to activate the compressor, plug a light or electronic device into the outlet to see if that powers on.
If the outlet works for other devices but not your compressor, pull back the housing that confines the switch, remove it from the socket and check the compressor owner’s manual for specs on the switch. Make sure that your replacement switch will match the specs and fit the socket.
